LS-Combi LS30T Portable Toilet Pump Out Station

Combi Station for Portable toilet  & Pump-out unit

• High quality housing made of polished stainless steel

• High capacity wastewater pump (LS30T)

• Built-in flush and rinse facilities.

• Remote discharge points for wastewater on request

• 2”(50mm) Discharge (waste) and DN 100 for gravity.

• Removable side for ease of installation.

• 230V 1~Ph on request

          Dimension

        Length total  = 1400mm
        Width  total  =   800mm
        Height  = 1740mm

          Data:

       Pump capacity:  up to 220l/min

       Motor capacity:  3,6kW

       Voltage:  400V /50Hz, 3~Ph

       Discharge pump:  2” female tread

       Discharge portaway:  110mm Pipe

       Suction pump:  2” female tread

       Operation:  start/stop

Only LeeSan truly specialise in toilets, call to speak to our knowledgeable staff.
